Brand Name :	WM-3D
Model Number :	VMS-3020F
Certification :	ISO9001 CE
Price :	$3,000.00/sets 1-1 sets
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :	2days

Add to Cart

Economic 2d manul Vision Measure Testing Machine VMS

Customized Optical Coordinate Measuring Machine 2D VMS Hand Control

Items	VMS-2010F		VMS-3020-F		VMS-4030F		VMS-5040F
Dimension(mm)(L×W×H)	5007001100		6007501100		7009001150		85010501200
Measuring range(mm)(X×Y×Z)	200100200		300200200		400300200		500400200
Measuring Accuracy(μm	3+L/200		3+L/200		3+L/200		3+L/200
Repeatability (μm)	3		3		3		3
Weight(kg)	150		180		200		240
Image and Measuring		CCD				Japanese SOnYCcD
		Len				WM HD zoom lens / continuous magnification 0.7-4,5x
		Magnification				30-210X
		ptical scale resolution				X/Y/zaxis 0.0005mm ( 0.5um
		Measuring range				9.omm-1.35mm
measuring system				Auxiliary focusing measurement, optical measuring altitude and flatness, and can be equipped with the British RENISHAW contact probe,
Driving system				versatile data processor can measures points, lines, loops, circles, angles, etc.
Illumination				Surface light and projection light , cold light, long life, brightness adjustable

Our advantage

♥High precision and high strength machine:00 marble base / upright cloumn / worktable, high precision and good stability.

♥XYZ three axis imported precision v type guide rail / imported optic axis drive system, long service life, good stability.

♥wMContinuous zoom optical lens,d ifferent frames, different magnification, without zoom correction.

♥HD Japanese SoNY ccD camera, high quality measuring screen.

♥Auxiliary focusing measurement, optical measuring altitude and flatness, and can be equipped with the British RENISHAW contact probe.

♥Surface light , LED profile light , coaxial light . choose match programmable three ring eight area light.

♥The laser pointer indicates the position of measuring,rapid positioning and convenient measurement.
