Function Description:

Element measurement: Measuring points, lines, circles, arcs, angles, oval, rectangle measuring a

predetermined number of points, automatic identification points, lines, circles, arcs.

Element structure: Center construction, the intersection of structure, the midpoint structure, line structure,

round structure, angle configuration.

Preset elements: points, lines, circles, arcs. Coordinate translation, straighten the workpiece. Straighten any

axis coordinate system reset.

Graphics: Graphics zoom, graphics narrowing, graphics pan, graphics selected, select the circle, delete the

graphic, graphic print. Zoom settings, set the image gray, saturation, contrast, save, images in BMP format.

A variety of edge finder mode, the computer automatically take points, automatic identification round, arc greatly

improve mining point speed.

Image support S-Video, AV terminal, USB terminal input; image size of 640 * 480mm. Measurement data directly

into AutoCAD for statistical analysis, can draw simple Xbar-s control chart obtained various parameters Ca.

Multilingual interface switching.
